Ultra High 95 CRI LED Strip Lights for Commercial & Retail
Ultra High 95 CRI LED Strip Lights for Commercial & Retail
Ultra High 95 CRI LED Strip Lights for Commercial & Retail
Ultra High 95 CRI LED Strip Lights for Commercial & Retail
Ultra High 95 CRI LED Strip Lights for Commercial & Retail

Ultra High 95 CRI LED Strip Lights for Commercial & Retail

3002.40

Regular price $139.00 $99.00 Sale

4000K OUT OF STOCK - SHIPS SEP 9
  • Color temperature of 4000K or 5000K for commercial and retail applications
  • Ultra high CRI values of 95 CRI and R9 > 90
  • High emitter density and brightness at 450 lumens per foot
  • Assembled and sold as a 16-ft reel (5 meters)
  • UL Listed, marking available on request
  • Requires DC 24V power to operate; power supplies sold separately
  • Product Overview

    For commercial and industrial applications where color accuracy and judgment are of utmost importance, higher color temperatures that closely simulate natural lighting conditions are needed. For retail applications, ultra high CRI in a neutral and comfortable 4000K provides an extra level of vivid color that makes merchandise pop and brings out their true colors.

    Waveform Lighting's ultra high CRI technology is now available as LED strips, in 4000K and 5000K, both with 95 CRI and R9 > 90.

  • Product Specifications

    Specifications Overview
    Color 4000K or 5000K
    CRI 95+
    Brightness 450 lumens per foot
    Voltage DC 24V
    Power 5.5 watts per foot
    Connection Style 16 AWG Cable (No Plug)
    Specification sheet download   Specification Sheet
    Specification sheet download   4000K Photometric Report
    Specification sheet download   5000K Photometric Report
  • Power Requirements

    This LED strip product requires a DC 24V power source to operate. We recommend a minimum power supply capacity of 96W when operating the entire 16 ft reel. Learn more about calculating power supply requirements here.

    This LED strip can be dimmed via a traditional wall-dimmer (e.g. Lutron/Leviton) or an inline dimmer (e.g. PWM FilmGrade dimmer). Use a dimmable power supply (PN 3096) when connecting to a traditional wall-dimmer system and a standard power supply (PN 3092) when using an inline dimmer.

  • Parts List for Wall-Dimmer Setup

    If you would like to dim your LED strip through a traditional wall-dimmer (phase cut / ELV dimmer from brands such as Lutron and Leviton), please reference the parts list below.

    Part Number Description
    PN 3096 DC 24V power supply, dimmable Required
    PN 3070 Use to connect cut LED strip section to a power supply Optional
    PN 3071 Use to connect cut LED strip sections to each other Optional
    PN 7098 DC cable to span sections between LED strip or power supply sections Optional
    - Traditional wall-dimmer unit (sold at hardware store) Required
    - Twist-on wire connectors (sold at hardware store) Required
  • Parts List for Non-dimmable or Inline PWM Setup

    If you do not need any dimming functionality (on/off only) or prefer to use an in-line PWM dimmer, reference the parts list below.

    Part Number Description
    PN 3092 DC 24V power supply, standard plug-in type Required
    PN 7094 DC plug adapter for PN 3091/3092, to convert to wire connections Required
    PN 3081 Inline PWM dimmer unit, installed between power supply and LED strip Required, if dimming
    PN 3070 Use to connect cut LED strip section to a power supply Optional
    PN 3071 Use to connect cut LED strip sections to each other Optional
    PN 7098 DC cable to span sections between LED strip or power supply sections Optional
    - Twist-on wire connectors (sold at hardware store) Required, if using using PN 7098
  • Pricing & Ordering Information

    Listed pricing is per one reel (16.4 ft / 5 meters). Please see below for part numbers and corresponding specifications.

    Part Number Specification
    PN 3002.40 4000K
    PN 3002.50 5000K
  • Shipping & Returns

    This item is in stock and typically ships within 1-3 business days. Shipping is free within the USA.

    If you're not 100% satisfied with the performance, color or quality of your product, we'll work with you to make it right.

    Simply contact us within 30 calendar days after delivery and we'll pay for return shipping (USA only) and offer you a full refund.

    See our delivery policy, returns & refunds policy and warranty policy.

Crisp & Accurate Colors



Don't let poor lighting conditions take away from professional and commercial success. For visually-oriented tasks and activities, higher color temperatures that more closely mimic natural light are important. High color rendering quality ensures that objects appear accurate and natural.



Crisp & Accurate Colors



Don't let poor lighting conditions take away from professional and commercial success. For visually-oriented tasks and activities, higher color temperatures that more closely mimic natural light are important. High color rendering quality ensures that objects appear accurate and natural.

Strong & Secure Adhesion



Pre-applied 3M VHB double-sided tape on the back side allows for simple but reliable installation. Peel back the liner and apply to virtually any surface. Architectural-grade adhesive ensures your LED strips stay in place.

Cut-to-Length



These LED strips can be cut to length in 2 inch intervals using just a pair of scissors.

Now you can install lighting to fit the exact length of any cabinet or interior feature. No more dark spots or uneven lighting!



Cut-to-Length



These LED strips can be cut to length in 2 inch intervals using just a pair of scissors.

Now you can install lighting to fit the exact length of any cabinet or interior feature. No more dark spots or uneven lighting!

Rejoin LED Segments

Conveniently rejoin cut LED segments using our PN 3071 solderless connectors. The connector cable is flexible, so you can also turn corners or change the direction of your LED strip run.




For A Softer Look



Aluminum channels, while optional, are great way to house and mount LED strip lights. Particularly for applications where the LED strip light is exposed, the aluminum channel and included diffuser can improve overall aesthetics and help disperse the light more effectively to eliminate glare.







  • Frequently Asked Questions

    • What type of power supply do I need?

      This LED strip product requires a DC 24V power supply to operate. For most residential and commercial installations, this means that the AC 120V (North America) or AC 240V (Europe) needs to be converted via a power supply unit.

      When choosing a power supply unit, you must ensure that the output voltage matches the LED strip voltage (i.e. DC 24V), and that the power supply capacity is sufficient to operate the length of LED strip.

      The power supply capacity needed is determined by the total length of LED strip connected. Each 1 foot section consumes 5.5 watts of power - so, for example, a 10 foot section will consume 55 watts of power, and we would therefore recommend a minimum power capacity of 55 watts.

      Typically, however, it is a good idea not to run a power supply at its maximum capacity. We recommend providing an extra 5-15% of "headroom" above the actual LED strip power consumption.


    • How do I connect this product to a power supply?

      Each reel of LED strip includes wire cables pre-mounted on both ends. The cables are 16 AWG and are 13.7 inches in length, with insulation trimmed & tinned at the ends.

      For hard-wired application, simply use twist-on wire connectors ("wire nuts") to connect the positive and ground wires to the corresponding DC output wires of the power supply unit.

      If using a power supply with a DC plug output, use an adapter such as PN 7094 to convert the DC plug to wire receptacles.


    • What is the maximum run length of this product?

      The maximum run length is 32.8 ft (two reels). The maximum run length represents the longest permitted length of LED strip that can be connected as a single consecutive run to a power supply.


    • Do these LED strips require heatsinking?

      Because the premium LEDs on this product are under-driven below their rated capacity, these LED strips can be operated without any heatsinking or additional thermal management.

      Temperature rise of the LED strips is typically 50 degrees Fahrenheit (20 degrees Celsius) over ambient.
